The Display Logger (DSB) is a featureful USB data logger. With the logger, it’s easy to collect temperature and humidity data from Dickson’s replaceable sensors. Works with the latest version of DicksonWare.

Product Details
DSB Specifications
Alarm TypePhone Call, SMS Text, Email, Audible *Alarms can be created for scenarios where the readings are outside a given range, communication has been lost, or the batteries are low. All paid accounts are eligible to receive email and SMS text alarm notifications.
Ambient Operating RH Conditions0-95% RH non-condensing
Ambient Operating Temperature Conditions32.0 to 158.0F (0.0 to 70.0C)
Antenna TypeInternal
ApprovalsRoHS, FCC Part 15 Compliance
Battery Life (Avg)1 Week
Calibration OptionsN100 , N300, N400, & N520
ChannelsOne Channel
Data CapacityApprox 400,000 sample points (backup)
Digital DisplayYes
Dimensions1.7 x 4.25 x 4.25in
Download TypeWireless
EnclosureGrey/White; ABS Plastic Clam Shell
Included AccessoriesNetwork Cable
IP Rating21
Calibration OptionsN100 , N300, N400, & N520
Mounting OptionsFree Standing or Wall Mount (With Keyhole)
PC can be accessed from any Windows, Mac, or Linux PC/Laptop using Google Chrome, FireFox, Safari, or Internet Explorer 9. WiFi loggers need a Windows or Mac PC with Java for initial configuration. WiFi loggers are compatible with WEP, WPA, and WPA2 Personal security protocols.
Power Source 120 to 240 VAC, 12 VDC (INTL fittings available)
Power Status IndicatorRed/Green/Blue/White/Yellow (RGB) LED
Radio Frequency2.4 GHz
Remote Probe DimensionsHouses thermistor sensor in polycarbonate plastic; 1.5" x 0.5" (1.25cm x 4.5cm)
Remote Sensor Length Optional 10 ft extension cable (up to 3 extension cables can be added without sacrificing accuracy)
Remote Sensor Type1 Field Replaceable Digital Sensor
Sample IntervalUser Selectable Sample Intervals: 60, 90 seconds / 2, 5, 10, 15, 30, 60 minutes. (10 and 30 seconds optional, please call for details)
Software Options All DicksonOne Data Loggers must be connected to a DicksonOne subscription to function correctly.
Storage Conditions RH 0-95% RH non-condensing
Temperature Range Temperature range varies based on the selected Replaceable Sensor/Probe.
Temperature Sensor Type Field Replaceable Digital Temperature Sensor
Unit Weight 3 lbs
Units/Pkg 1

Almost all Dickson products are covered by Dickson’s Manufacturer’s Warranty.
