Compact Data Logger
SKU:DBL
Starting from
$93.00
Good things come in small packages. Start/Stop functionality for the most precise data collection needs along with a digital display that provides current Temperature and Relative Humidity readings. Perfect for mapping warehouses or large stability chambers. Quantity Pricing Available. Call 630.543.3747 to learn more.
- Dicksonware™ 2.0 Standard Software Included
- Digital Display
- Battery Powered
- Multi-colored LED Indicator Light
Summary
Product
Price
Compact Data Logger
Base Unit
Select Option
Related Products
DicksonOne Display Logger
<p>The DicksonOne Display Logger (DWE) automatically sends its data up to DicksonOne where it is stored and can trigger user-configured alarms (among many other features).</p>
<ul>
<li>Email, Text, & Phone alarms</li>
<li>Unlimited Data Storage</li>
<li>Remote access for an unlimited number of users anywhere you have internet</li>
</ul>
DicksonOne Touchscreen
<p>A capacitive 8″ touchscreen offers our best user experience ever and now features customizable views, alarms, and more. Plus, with cloud-based DicksonOne, you get your data at your fingertips and wherever else ou might need it.</p>
Dicksonware 2.0 Secure (Micro USB)
<p>With DicksonWare™ Secure (21 CFR 11 Compliant), you can download your environmental data to your PC securely. Micro USB cable included.</p>
Display Logger (USB)
<p dir="ltr">The fully redesigned Dickson Display Logger (DSB) incorporates features from our best selling devices into non-connected units. With the logger, it’s easy to collect temperature and humidity data from Dickson’s Replaceable Sensors™. Let Dickson be proactive about your data so you don’t have to be!</p>
<p dir="ltr">Features:</p>
<ul>
<li>USB enabled for fast downloading with Legacy Uploader</li>
<li>Easy-to-use interface</li>
<li>Audio and Visual alarms</li>
<li>Compatible with Replaceable Sensors™ (Patent Pending)</li>
</ul>
<p dir="ltr">Using the latest version of <a href="https://dicksondata.com/product/dicksonware-2-0">DicksonWare™ Software</a>, you can set up your Dickson loggers, view and download data, and reset your logger to the factory settings. Software sold separately.</p>
Product Details
Compact Data Logger Specifications
| Ambient Operating RH Conditions | 5%-95% non-condensing |
| Ambient Operating Temperature Conditions | DBL: 0F to 131F DBL-EX: -40F to 160F |
| Battery Life (Avg) | DBL: 2years (Alkaline AA) DBL-EX: 5years (Li-ion) Assumes 5 min sample rate |
| Channels | Channel 1 Temperature Channel 2 Humidity |
| Data Capacity | 500,000 total |
| Delayed Start | Yes |
| Dimensions | 2.67 in x 2.16 in x 1.00 in |
| Download Time | 25 minutes (Max) |
| Humidity Accuracy | (+/-) 3.0% |
| Humidity Range | 5%-95% non-condensing |
| IP Rating | IP 20 |
| Included Accessories | One AA Battery Wall Mount Quick Start Guide AC Adapter (sold separately) Software included |
| Memory Type | EEPROM |
| Minimum Software Version Required | DicksonWare 20.3.2.0 |
| PC Requirements | Windows 7 and newer |
| Power Source | MicroUSB (A075), AA Batteries |
| Sample Interval | User Selectable (60, 90 seconds, 2, 5, 10, 15, 30 minutes, and 1 hour). |
| Software Options | SW05, SW06 |
| Temperature Accuracy | (+/-) 1.2F |
| Temperature Range | DBL: 0F to 131F DBL-EX: -40F to 160F |
| Display Type | LCD |
| Display Dimensions | 1.80 in x 1.20 in |
| Display Resolution | 0.1 |
| Display Update Rate | 3 seconds |
| Power Status Indicator | LCD display |
| Response Time | 10 min to 63% of full scale |
| Unit Weight | 2.4 ounces |
| Alarms | Audible, LED, LCD display |
| Cable Details | MicroUSB |
Almost all Dickson products are covered by Dickson’s Manufacturer’s Warranty.
